主要特性和功能

· 豐富的測試儀選件，您可以選擇最適合自身測試需求的配置：100 kHz 至 1.5 GHz/3 GHz，2 端口，50 或 75 Ω，傳輸/反射或 S 參數測試儀

· 使用低頻-射頻選件（選件 3L5/3L4/3L3）滿足各類應用需求：5 Hz 至 3 GHz，2 端口，50 Ω，S 參數測試儀，增益相位測試端口，內置的直流偏置源

· 在單一儀器中整合了網絡分析和阻抗分析兩大功能，可以定制您的應用（選件 3L5/3L4/3L3 和 005）

選件：

Test set

E5061B-3L5 LF-RF network analyzer with DC bias source, 5 Hz to 3 GHz

E5061B-235 S-parameter test set, 100 kHz to 3 GHz, 50 ohm system impedance

E5061B-217 S-parameter test set, 100 kHz to 1.5 GHz, 75 ohm system impedance

E5061B-215 S-parameter test set, 100 kHz to 1.5 GHz, 50 ohm system impedance

E5061B-137 Transmission/Reflection test set, 100 kHz to 3 GHz, 75 ohm system impedance

E5061B-135 Transmission/Reflection test set, 100 kHz to 3 GHz, 50 ohm system impedance

E5061B-117 Transmission/Reflection test set, 100 kHz to 1.5 GHz, 75 ohm system impedance

E5061B-115 Transmission/Reflection test set, 100 kHz to 1.5 GHz, 50 ohm system impedance

E5061B-237 S-parameter test set, 100 kHz to 3 GHz, 75 ohm system impedance

E5061B-3L3 LF-RF network analyzer with DC bias source, 5 Hz to 500 MHz

E5061B-3L4 LF-RF network analyzer with DC bias source, 5 Hz to 1.5 GHz

Timebase stability

E5061B-1E5 High stability timebase

Hard disk drive option

E5061B-020 Standard Data Storage

Additional features

E5061B-010 時域分析/故障定位分析

E5061B-005 用于 E5061B ENA LF-RF 矢量網絡分析儀的阻抗分析選件（選件005）

E5061B-006 無線功率傳輸分析

Calibration documentation

E5061B-A6J ANSI Z540-1-1994 Calibration

E5061B-1A7 Calibration + Uncertainties + Guardbanding (Not Accredited)

E5061B-721 Add GPIB

E5061B-722 Not required GPIB

E5061B-731 Add Handler IO

E5061B-732 Not required Handler IO
